Middle East Series
Project Grade Ballasts 127V/220V - MLT 120-240V
Features
- Rapid start
- High Power Factor ( HPF)
- End of Life protection
- Multiple lamp operation
- Suitable for T8 and T12 operation
- Solid housing and compact case
Applications
- Decorative Lighting
- Indoor Architectural Lighting
- Outdoor Architectural Lighting
- Industrial and Commercial Lighting
Common Specifications/Case Sizes - 127/220V
Common Specifications – 127/220V
- Input Voltage: 127V ± 10%, 50/60Hz • 220V ± 10%, 50/60Hz
- Power Factor: > 0.98
- Efficacy Factor: > 88%
- THD: < 10%
- Current Crest Factor: < 1.7
- EMI/RFI Compliance: FCC PART 18-A (Non Consumer)
- Sound Rating: A
- Ballast Type: Rapid Start Voltage Transients: ANSI 62.41
- Min. Operating Temp: -10ºC ( 14ºF )
- Max. Case Temp: 75ºC ( 167ºF )
- Approvals/Class: UL Listed, CLASS P 1 OUTDOOR
Case Sizes
- WHSG5-127/220 – Ballast Size (mm): 235 L x 40 W x 25.4 H
- WHSG6-127/220 – Ballast Size (mm): 235 L x 40 W x 25.4 H
- WHSG9-127/220 – Ballast Size (mm): 255 L x 40 W x 25.4 H
Common Specifications/Case Sizes - MLT 120-240V
Common Specifications – MLT 120-240V
- Input Voltage: 120V-240V ± 10%, 50/60Hz
- Power Factor: >0.98
- Efficacy Factor: >88%
- THD: <10%
- Current Crest Factor: <1.7
- EMI/RFI Compliance: FCC PART 18-A (Non Consumer)
- Sound Rating: A
- Ballast Type: Rapid Start
- Voltage Transients: ANSI 62.41
- Min. Operating Temp: -10ºC ( 14ºF )
- Max. Case Temp: 75ºC ( 167ºF )
- Approvals/Class: UL Listed, CLASS P 1 OUTDOOR
Literature and Spec Sheets
Lamp Operation 127V/220V
Lamp Operation MLT 120/240V
† These products have previously been tested as per SASO guidelines and comply with the SASO standards. If you are interested in your shipment being accompanied by a SASO conformity certificate, this can be arranged at cost for the testing. Please contact the Middle East regional office for details.
