Lumo Series LED Drivers

Lumo Series European LED Drivers

  • Designed and manufactured in Europe with exceptional standards for performance and reliability
  • Constant current and constant voltage models
  • Adjustable output currents and low inrush current
  • Thermal, overload, and overvoltage protection
  • Dimming options include 1-10V, Mains/Trailing Edge, and DALI
  • 3D Models available upon request: contact us

Lumo Series Constant Current LED Drivers »
Lumo Series Constant Voltage LED Drivers »

Lumo Series Constant Current Drivers



Model Number Prior Model Numbers Max Watts (W) Output Current (mA) Input Voltage (VAC) Dimming Downloads
L1MLT0350-5.5C L05150 6 350 100-240 (50/60 Hz) Non-Dimmable Spec Sheet
Manual
L1MLT0680-6.5C L05050 7 700 100-240 (50/60 Hz) Non-Dimmable Spec Sheet
Manual
L1E1230025S-10E L05021-40250 10 200/250 220-240 (50/60Hz) Trailing Edge / Mains Dimmable Spec Sheet
Manual
L1MLT020S-10E48 L05020-1248200 10 150/200 115-240 (50/60 Hz) Non-Dimmable Spec Sheet
L1E1230030S-12E L05020-1248200 12 180/300 220-240 (50/60Hz) Trailing Edge / Mains Dimmable Spec Sheet
Dimmer List
L1E1230070S-12E L05021-40300 12 350/700 220-240 (50/60 Hz) Trailing Edge / Mains Dimmable Spec Sheet
Dimmer List
L1MLT030S-12E48 L05021 12 250/300 115-240 (50/60 Hz) Non-Dimmable Spec Sheet
L1MLT050S-12E40 L05020-1248300 12 400/500 115-240 (50/60 Hz) Non-Dimmable Spec Sheet
L1MLT070S-12E40 L05020-1240500 12 350/700 115-240 (50/60 Hz) Non-Dimmable Spec Sheet
L1MLT082S-12E24 L05020-1240700 12 600/825 115-240 (50/60 Hz) Non-Dimmable Spec Sheet
L1LDC070S-20E L05020-1224825 20 700 24-32 (50/60Hz) Non-Dimmable Spec Sheet
Manual
L1M1MLT105S-20E L05011i 20 350/700/1050 110-240 (50/60Hz) 0-10V/1-10V/Potentiometer/Pulse Spec Sheet
Manual
L1MLT0500-20E L05013-40500 20 500 115-240 (50/60Hz) Non-Dimmable Spec Sheet
Manual
L1MLT140S-20E L05012 20 350-1400 115-240 (50/60 Hz) Non-Dimmable Spec Sheet
Manual
L1W1MID120D-20E L05011i2 20 100-1200 180-240 (50/60Hz) 0-10V/1-10V/Potentiometer/Pulse Spec Sheet
Manual
L1W1MLT500S-20E L05016Ci 20 110-500 110-240 (50/60 Hz) 0-10V/1-10V/Potentiometer/Pulse Spec Sheet
Manual
L1W2MLT100S-20E L05016i 20 110-500 110-240 (50/60 Hz) 0-10V/1-10V/Potentiometer/Pulse Spec Sheet
Manual
L1M1MID120S-24E L05011i3 24 20W: 200-120024W:600-900 180-240 (50/60 Hz) 1-10V Spec Sheet
Manual
L1V1230105S-25E L05023-A 25 100-1050 220-240 (50/60 Hz) Mains Dimmable Spec Sheet
Manual
L1A1MID100S-30E L05025 30 100-1000 220-240 (50/60 Hz) DALI Spec Sheet
Manual
L1W1MID140S-30E L05031 30 100-1400 180-240 (50/60 Hz) 1-10V Spec Sheet
Manual
L1A1MID100S-40E L05040 40 100-1000 180-240 (50/60 Hz) DALI Spec Sheet
Manual
L1M1MLT105S-40E L05049-601000 40 245-1050 110-240 (50/60 Hz) 1-10V Spec Sheet
Manual
L1M1MLT140S-40E L05045 40 300-1400 110-240 (50/60 Hz) 1-10V Spec Sheet
Manual
L1MLT140S-40E L05044 40 300-1400 160-240 (50/60 Hz) Non-Dimmable Spec Sheet
Manual
L1M1230140S-60E L05059 60 500-1400 220-240 (50/60 Hz) 1-10V Spec Sheet
Manual
L1M1230200S-60E L05055 60 700-2000 220-240 (50/60 Hz) 1-10V Spec Sheet
Manual

Lumo Series Constant Voltage Drivers



Model Number Prior Model Number Max Watts (W) Output Voltage (VDC) Output Current (mA) Input Voltage (VAC) Dimming Downloads
L1M1MLT105S-20E L05011i 20 10/12/24 150-1200 180-240 (50/60 Hz) 0-10V, Potentiometer, Pulse Spec Sheet
Manual
L1MLT024V-36E L05046 36 24 1050 110-240 (50/60 Hz) Non-Dimmable Spec Sheet
Manual
